high speed automatic steel wire nails making machine
A brief overview of the nail making machine:
Nail making machine is a production equipment used to make iron nails. Also known as nail making machine equipment, used steel nail making machine, it is easy to operate and use, it has low power, energy saving, stable and reliable performance. The quality is up to standard. The equipment has the characteristics of small size, flexible and convenient movement, low noise, low power consumption, and easy installation. Therefore, the project has become an ideal project for enterprises, individuals, families, laid-off workers, and farmers to get rich quickly.
The nail making machine is mainly divided into four parts, the more important one is wire drawing. When you buy nails, you must determine what kind of steel bars will be used for nailing in the future, such as new steel bars, waste steel bars, etc.. The drawing of waste steel bars is more troublesome, not as fast as new steel bars, but the cost and profit of waste steel bars are very considerable. The wire drawing speed is very fast, which can save a considerable part of labor. And the nail wire pulled out with new steel bar is also very fast.
|Nail length range||15-25mm||20-35mm||28-50mm||50-100mm||75-150mm|
The complete set of equipment for the new automatic nail making machinery includes the new automatic nail making machine, wire drawing machine, polishing machine and other auxiliary equipment. Here, the most important thing is the new automatic nail making machine, and how can the new automatic nail making machine do Make a good nail, don’t ignore the role of the nail cutter, because in the new automatic nail making machine, when the cams on the left and right shafts rotate, the scissors slider will be affected, and the nail cutter will move back and forth to the left and right. The purpose of cutting off nails can be achieved. Whether the nail tip of the nail is sharp or the nail tip is not bent, these are the functions of the nail cutter of the new automatic nail making machine.
So, in the process of using the new automatic nail making machine, how should we choose and use the nail cutter of the new automatic nail making machine?
The choice of nail knives for the new automatic nail making machine, the choice of nail knives for the new automatic nail making machine, we mainly look at the material, the nail knives of the new automatic nail making machine are platinum knives and carbide knives, our most ideal Carbide knife can be selected as the material of the nail knife of the new automatic nail making machine. Because it has relatively high quality and energy efficiency.
The use of the nail knives of the new automatic nail making machine, first of all is the adjustment of the nail knives of the new automatic nail making machine: the new automatic nail making machine knives need to be adjusted reasonably, and the two nail knives cannot be matched too tightly. , And can’t be too lenient, otherwise it will increase the loss of nail knives.
Secondly, when using the new automatic nail making machine, the surface of the iron wire should be kept as smooth as possible. For example, there are burrs on the surface of the iron wire, which will also further increase the loss of nail cutters. Only by replacing the wire drawing die can the problem be alleviated. Appropriate raw materials should be selected. If the hardness of the raw materials for nail making is high, the loss of the new automatic nail machine tools will inevitably be more serious. Let's talk about the maintenance of the new automatic nail making machine tool: the nail knife of the new automatic nail making machine should be kept sharp at all times. After the new automatic nail making machine is started, the standby device should be in normal operation before pulling the line handle. When entering the wire for nail making, stop entering the wire first when stopping. During the operation of the new automatic nail making machine, attention should be paid to the temperature rise changes of the friction parts and the occurrence of abnormal noises at all times. The nail knives of the new automatic nail making machine should also be lubricated regularly to ensure that the lubrication parts are well lubricated. Therefore, the use of the new automatic nail making machine tools cannot be ignored, and the maintenance of the new automatic nail making machine tools is also very important.
The role of the nail parts of the Z94-4C nail making mechanism:
1. The role of the scrap steel wire drawing machine: according to the length of the nail you make, draw it to the corresponding diameter.
2. The function of the polishing machine: Put the semi-finished nails into the interior for processing, and put some chemical materials such as paraffin and oil in them to remove the embroidery on the surface of the nails.
3. The function of the knife sharpener: the nail making machine wears alloy knives, and the knife will be dull after a long nailing time. Take the knife from the nail making machine and polish it with the knife sharpener, and then use it again. reason.
4. Outgoing function: the thrown nails are packed in cartons, wooden boxes, woven bags, etc., which are more convenient for transportation, and shipped to various dealers and construction sites.
Maintenance requirements for automatic nail making machine:
1. When the automatic nail making machine is used, it is better to carry out a large amount of lubrication within 15 days. Lubricate oil regularly to ensure that all lubricated parts are well lubricated.
2. After starting the automatic nail making machine, the standby device must be in normal operation before turning the wire-in handle to wire-in nails. The wire-in should be stopped when the machine is stopped.
3. Do not make adjustments while the machine is in motion.
4. During the operation of the machine, attention should be paid to the temperature rise changes of the friction parts and the occurrence of abnormal noises at all times
5. Disconnect the power supply first when repairing equipment or electrical appliances.
6. The original specifications of the nail making machine should be used for the equipment that needs to be replaced.
7. Keep the nail knife sharp.
8. Do not drive without removing the protective cover.
9. Keep the machine tidy and clean the nail mold frequently. Do not use rusty wire when nailing.
The fully automatic formulating machine is specially designed for the manufacture of round nails of various specifications. It has a complete model and can produce a variety of yuan nails and special-shaped nails. It has a wide range of uses, simple operation, safe use, and reliable operation. It can provide you with a variety of Accessories. And provide a variety of supporting sophisticated auxiliary machines.
Common faults and troubleshooting methods on the top part of the automatic nail making machine equipment:
1. The top is cracked. The reason may be that the nail wire clamps dust or the nail wire hardness is too high, the nail wire needs to be replaced or tempered, or the nail knife is inaccurate. The nail knife must be sharpened according to the specified requirements.
2. Nail flashing. There are three reasons for this failure. The first is that the sharp edge of the nail knife is not straight, and the nail knife needs to be sharpened. The other is that the hardness of the nail knife edge is too low, and the hardness of the nail knife needs to be improved. It's because the nail wire is different in softness and hardness, just exchange the nail wire.
3. If the top is not right, it may be that the size of the nail knife blade is inconsistent, so you need to sharpen the nail knife again. Another kind of situation is that the position of the knife blade is wrong. Just re-adjust the position of the nail knife.
